R4-35A Block Moulding Machine
Stationary block moulding machine with a 35-second cycle, raising output to 15,000 standard bricks per shift at 4.8 kW.
Power4.8 kWMoulding cycle35 sWeight750 kg
Indicative priceEXW US$1,480Ex-works China. Freight, packing and duties are quoted per destination.
Key features
- 35-second cycle — a 28% faster cycle than the R4-45 machines
- Higher output from the same footprint as the large mobile machine
- Manual/mechanical mould lifting with vibration-motor compaction
- Custom mould box available for pavers and shaped blocks
Quick answer
The R4-35A is a stationary block moulding machine running a 35-second cycle — 28% faster than the 45-second range — for an output of about 15,000 standard bricks or 2,400 hollow blocks per eight-hour shift from a 4.8 kW drive. It occupies the same 1,250 × 1,350 × 1,550 mm footprint and the same 750 kg build as the mobile R4-45, but is set up as a fixed-yard machine.
How many blocks does the R4-35A produce per shift?
About 15,000 standard bricks (240 × 53 × 115 mm) or 2,400 hollow blocks (390 × 190 × 190 mm) in an eight-hour shift, at one block every 35 seconds.
What is the difference between the R4-35A and the R4-45?
Same footprint and the same 750 kg machine weight, but different drive and cycle: the R4-45 runs 3.7 kW on a 45-second cycle for about 12,000 standard bricks per shift, and the R4-35A runs 4.8 kW on 35 seconds for about 15,000. The R4-45 is the mobile machine; the R4-35A is the fixed-yard model.
Does the R4-35A load itself?
No. The R4-35A uses manual/mechanical mould lifting and the mould box is charged by hand. The R4-35AH is the same machine with an integrated charging hopper that removes that step.
What does the R4-35A cost and what is included?
EXW US$1,480 including one steel mould box. A customised mould box for pavers and shaped blocks is US$420.
Specification
Factory figures for the R4-35A. Confirm the final configuration on your quotation — options listed here are quoted separately.
R4-35A — technical data
Machine
| Overall size | 1,250 × 1,350 × 1,550 mm |
|---|---|
| Power | 4.8 kW |
| Voltage | 380 V / 220 V |
| Moulding cycle | 35 s |
| Machine weight | 750 kg |
Output per shift
| Standard brick 240 × 53 × 115 mm | 15,000 pcs |
|---|---|
| Hollow block 390 × 190 × 190 mm | 2,400 pcs |
Supply
| Included mould | 1 mould box |
|---|---|
| Customised mould | US$420 |
| Price | EXW US$1,480 |
Figures are factory data from the manufacturer's specification sheets and catalogue.
Where it is used
- Fixed precast yards running a full production shift
- Supplying building-material distributors with standard brick
- Producing hollow blocks for walling systems
