R4-35AH Block Moulding Machine with Hopper
The R4-35A with an integrated charging hopper, cutting manual loading time and lifting output to 20,000 standard bricks per shift.
Power4.8 kWMoulding cycle35 sWeight780 kg
Indicative priceEXW US$1,690Ex-works China. Freight, packing and duties are quoted per destination.
Key features
- Integrated charging hopper replaces hand-shovelling the mould box
- 20,000 standard bricks per shift on a 35-second cycle
- Taller frame (1,950 mm) to suit the hopper feed height
- Custom mould box available for pavers and shaped blocks
Quick answer
The R4-35AH is the R4-35A with an integrated charging hopper, and that single change takes output from about 15,000 to about 20,000 standard bricks per eight-hour shift, or 3,200 hollow blocks. The 4.8 kW drive and 35-second cycle are unchanged; the frame is taller at 1,950 mm to suit the hopper feed height.
How many blocks does the R4-35AH produce per shift?
About 20,000 standard bricks (240 × 53 × 115 mm) or 3,200 hollow blocks (390 × 190 × 190 mm) in an eight-hour shift, at one block every 35 seconds.
How does the hopper raise output without changing the cycle time?
The cycle stays at 35 seconds and the drive stays at 4.8 kW. What the hopper removes is the hand-shovelling of the mould box, which is the step that limits the R4-35A. That is the whole of the difference between about 15,000 and about 20,000 standard bricks per shift.
Why is the R4-35AH taller than the R4-35A?
It stands 1,950 mm against the R4-35A at 1,550 mm, because the hopper feeds from above. Check the headroom of the building before committing to this model.
What does the R4-35AH cost and what is included?
EXW US$1,690 including one steel mould box. A customised mould box for pavers and shaped blocks is US$420.
Specification
Factory figures for the R4-35AH. Confirm the final configuration on your quotation — options listed here are quoted separately.
R4-35AH — technical data
Machine
| Overall size | 1,200 × 1,280 × 1,950 mm |
|---|---|
| Power | 4.8 kW |
| Voltage | 380 V / 220 V |
| Moulding cycle | 35 s |
| Machine weight | 780 kg |
Output per shift
| Standard brick 240 × 53 × 115 mm | 20,000 pcs |
|---|---|
| Hollow block 390 × 190 × 190 mm | 3,200 pcs |
Supply
| Included mould | 1 mould box |
|---|---|
| Customised mould | US$420 |
| Price | EXW US$1,690 |
Figures are factory data from the manufacturer's specification sheets and catalogue.
Where it is used
- Yards where labour for manual charging is limited
- Continuous-shift production of standard brick
- Hollow block production at distributor volumes
