RD2-45 Diesel Mobile Block Making Machine
Diesel-driven mobile block machine for sites without a mains electricity supply, moulding on the same 45-second cycle.
DriveDiesel engineMoulding cycle45 sWeight250 kg
Indicative priceEXW US$1,060Ex-works China. Freight, packing and duties are quoted per destination.
Key features
- Self-powered by an 8 hp diesel engine — no mains connection needed
- Same 45-second cycle as the electric R2-45
- Suited to remote sites and regions with an unreliable grid
- Ships with one mould box; further profiles quoted separately
Quick answer
The RD2-45 is the diesel-driven machine in the range: an 8 hp engine powers the same 45-second cycle and the same output as the electric R2-45, about 3,600 standard bricks or 600 hollow blocks per eight-hour shift, with no mains connection at all. It exists for sites where there is no grid supply or the supply is not reliable enough to run a machine.
Can the RD2-45 run without electricity?
Yes. It is self-powered by an 8 hp diesel engine and requires no mains connection, which is the reason to choose it over the otherwise comparable electric R2-45.
Is the output the same as the electric R2-45?
Yes. Both mould one block every 45 seconds and produce about 3,600 standard bricks (240 × 53 × 115 mm) or 600 hollow blocks (390 × 190 × 190 mm) in an eight-hour shift. The drive is the only difference.
How big is the RD2-45 to transport?
It measures 1,900 × 1,000 × 1,550 mm and weighs 250 kg. The longer frame carries the engine alongside the mould box.
What does the RD2-45 cost and what is included?
EXW US$1,060 including one steel mould box. A customised mould profile is US$225 extra. Budget separately for diesel.
Specification
Factory figures for the RD2-45. Confirm the final configuration on your quotation — options listed here are quoted separately.
RD2-45 — technical data
Machine
| Overall size | 1,900 × 1,000 × 1,550 mm |
|---|---|
| Power | 8 hp diesel engine |
| Moulding cycle | 45 s |
| Machine weight | 250 kg |
Output per shift
| Standard brick 240 × 53 × 115 mm | 3,600 pcs |
|---|---|
| Hollow block 390 × 190 × 190 mm | 600 pcs |
Supply
| Included mould | 1 mould box |
|---|---|
| Customised mould | US$225 |
| Price | EXW US$1,060 |
| Power supply | Not required — self-powered |
Figures are factory data from the manufacturer's specification sheets and catalogue.
Where it is used
- Rural and remote construction sites without grid power
- Contractors working across several sites with no fixed yard
- Regions where diesel is more reliable than mains electricity
