High-Speed Edge Trowel — 570 mm Disc

Light 55 kg edge trowel with a 570 mm disc, sized for working up to walls, columns and door openings that a full-size trowel cannot reach.

Disc size570 mmOutput power5 hpWeight55 kg
PriceQuoted to your specification

Send the configuration, quantity and destination port and we will quote it with the packed dimensions and weight.

Key features

  • Compact 570 mm disc reaches edges, corners and door openings
  • 55 kg — light enough for one operator to move between pours
  • Four-blade head for a smooth finish on edge strips
  • Cage guard and folding handle for transport

Quick answer

The 60 type is a 55 kg edge trowel with a 570 mm disc running at 110 rpm from a 5 hp petrol engine. It reaches the strip a full-size trowel cannot - alongside walls, columns and door openings.

What is an edge trowel used for?

Trowelling edges and margins alongside walls and columns, finishing small slabs, patios and utility floors, and tight-access pours that a 1000 mm walk-behind trowel will not fit into.

How heavy is it, and can one person move it?

55 kg, which is light enough for one operator to move between pours. The head carries four blades on a 570 mm disc at 110 rpm.

Does it travel between sites easily?

It has a folding operator handle and a cage-type blade guard. Blades and guard parts are available separately if you run a hire fleet.

What does it cost?

On request. Tell us how many you need and where they are going and we will quote it.

Specification

Factory figures for the 60 type. Confirm the final configuration on your quotation — options listed here are quoted separately.

60 type — technical data
Performance
Disc size570 mm
Blade count4 blades
Output power5 hp
Disc speed110 rpm
EnginePetrol, recoil start
Body
Weight55 kg
GuardCage-type blade guard
HandleFolding operator handle
Supply
PriceOn request
Spare partsBlades and guard parts available separately

Figures are factory data from the manufacturer's specification sheets and catalogue.

Where it is used

  • Trowelling edges and margins alongside walls and columns
  • Finishing small slabs, patios and utility floors
  • Tight-access pours where a 1000 mm trowel will not fit
