Big Paver Mould — Interlocking

A PP paver mould for casting interlocking concrete paving stones, quoted at more than 800 reuses.

MaterialPPPaver size200 × 200 mmMould life800 timesMOQ500 pieces
PriceQuoted to your specification

Send the configuration, quantity and destination port and we will quote it with the packed dimensions and weight.

Key features

  • Made of PP (polypropylene) — the supplier cites grade EP200k imported from Sinopec.
  • Reusable more than 800 times.
  • Highly interlocking design, so the laid pavers lock together.
  • Widely used for street, walkway and driveway paving, and for villa, park and garden decoration.

Quick answer

The big paver mould is a PP mould for casting interlocking concrete paving stones of 200 × 200 mm, reusable more than 800 times. The interlocking profile is what makes the laid pavers lock together rather than sit side by side.

How many times can the mould be reused?

RENFA quotes more than 800 times. The supplier description for this range also cites a 1,500 to 2,000-time reuse life, so the two figures do not agree - confirm which applies to your order.

What paver does it cast, and how strong is it?

A 200 × 200 mm interlocking paver. With 400# cement the pavers take a compressive strength of 400 to 500 kg/cm², which is the manufacturer's figure.

What is the mould made of?

PP (polypropylene) - the supplier cites grade EP200k imported from Sinopec. Plastic, rubber, PP or ABS can be supplied on request, and the standard colour is white.

What is the minimum order, and what is the lead time?

500 pieces, packed in woven bags. The listing quotes 25 days for 1 to 5 and negotiated above 5, which reads as orders rather than pieces, so confirm it at enquiry. Logo, packaging and graphics can be customised from 1,000 pieces.

Specification

Factory figures for the Customised. Confirm the final configuration on your quotation — options listed here are quoted separately.

Customised — technical data
Mould
Shaping modePlastic injection moulding
ProductPlastic paver mould
MaterialPlastic; rubber, PP or ABS on request
ColourWhite
Size200 × 200 mm
Mould life800 times
ShapeMany kinds
Use
UsageConcrete casting
Paver performanceWith 400# cement the pavers take a compressive strength of 400–500 kg/cm² (manufacturer's figure)
NoteThe supplier description also quotes a 1,500–2,000-time reuse life for this range — confirm which applies to your order
Order
MOQ500 pieces
PackageWoven bags
Lead time25 days for 1–5 pieces; negotiated above 5
CustomisationLogo, packaging and graphics from 1,000 pieces
Shipping
Single package45 × 45 × 25 cm
Gross weight1.5 kg

Figures are factory data from the manufacturer's specification sheets and catalogue.

Where it is used

  • Street pavement
  • Walkways and driveways
  • Villas
  • Parks and gardens
