Adjustable Square Column Mould 675 × 600

Adjustable plastic column mould for casting square columns from 200 mm to 600 mm from a single set, with a 600 mm forming height.

Mould size675 × 600 mmForming height600 mmAdjustment200 – 600 mm
PriceQuoted to your specification

Send the configuration, quantity and destination port and we will quote it with the packed dimensions and weight.

Key features

  • Five column widths from one set — 200 mm up to 600 mm
  • Reusable plastic construction for repeated casting cycles
  • Material choice of PP, virgin PP or ABS
  • Stackable sets cast a full column in successive lifts

Quick answer

The 675 × 600 adjustable column mould casts square columns from 200 mm up to 600 mm from a single set, with a 600 mm forming height. Five widths come from the one mould.

Which column widths does it cast?

200, 300, 400, 500 and 600 mm - five widths from the one set.

How do I produce a full-height column?

The sets are stackable, so a full column is cast in successive 600 mm lifts rather than needing a taller mould. That is what keeps one set covering a whole order.

What material should I choose?

PP, virgin PP or ABS, chosen for the surface finish and the working life you need. The sets are reusable through repeated casting cycles.

What does it cost, and can I get a custom size?

On request - specify the material. Custom sizes are developed from your drawings or samples.

Specification

Factory figures for the 675 × 600. Confirm the final configuration on your quotation — options listed here are quoted separately.

675 × 600 — technical data
Adjustment
Adjustable column sizes200 / 300 / 400 / 500 / 600 mm
Forming height600 mm per set
Mould
Mould size675 × 600 mm
Material optionsPP, virgin PP or ABS
TypeReusable adjustable plastic mould
Supply
PriceOn request — specify material
CustomisationCustom sizes developed from your drawings or samples

Figures are factory data from the manufacturer's specification sheets and catalogue.

Where it is used

  • Precasting larger decorative and structural columns
  • Producing a size range without holding separate fixed moulds
  • Columns for porches, verandas and landscape features
